Sweeper

Five brush Sweeper

Number

1 Model YX-16A

2 Sweeping width 1600mm

3 Main brush width 700mm

4 working efficiency 8000-13500m2/h

5 working hours 3-8h

6 Dustbin capacity 180L

Complete 7 Side-brush diameter 600mm

vehicle 8 Walking speed 0-14km/h

9 0verall dimensions 1800*1580*2000mm

10 water tank 80L

11 Vacuum filtration 6m2area

12 Tyre type Front 400-8, rear 400-8 solid tyre

13 control mode Intelligent control system (timed dust

shaking function)

1 Headlight Four way LED headlights

Warning 2 tail light Steering+braking+driving integrated

taillights

lights 3 Alarm lamp Top operation warning light

4 HD reverse camera

1 Type Lead acid maintenance free (optional with

Storage lithium battery)

battery Standard 48V-100AH*4/150AH*6 lead-acid

2 Battery capacity

battery

1 Walking motor l000W intelligent gear change

Electrical 2 Rolling brush motor 1000W

machinery 3 side-brush motor 2*100W

4 Motor voltage 48V

Rearview model Dedicated for sweeping vehicles

1 mirror

Note: Standard single fan.optional with double fan.

Machine performance: The combination of suction, sweeping, and spraying effectively

suppresses dust and thoroughly cleans ground waste and dust.

Place of use: Used for cleaning workshop, parks, streets, lanes,

docks, property

communities,

warehouses, sports venues, schools, airports, and other areas in the

factory area The cleaning efficiency is l0 times that of the traditional manual

cleaning, and one sweeper can replace 8-12 Cleaner.
